Description
CBB61 type ceiling fan capacitor with frequency of 50/60Hz AC power supply, rated voltage 450V, 0.8 mfd capacity, reliable insulation performance and long service life, is suitable for starting and running of various electrical motors.
Specification
- Model: ATO-FC-CBB61-008
- Capacity: 0.8μF
- Rated Voltage: 450V
- Tolerance: ±5%
- Withstand Voltage: 2. 0 Un (2s)
- Loss: (DF)≤0.0010 100Hz
- Insulation Resistance: CxRs≥3000S (23℃, 1000VDC, 1min)
- Rated Frequency: 50/60Hz
- Climate Category: 40/105/21
- Scope of Application: Start, run
- Appearance: Rectangular
- Lead Out Method: Cord, pin, insert
- Dielectric Material: Organic thin film
- Dimension: 36(W) x 10(L) x 18(H)mm
- Certificate: CE, CQC
0.8μF Fan Capacitor 2 Wire Circuit Diagram
Ceiling Fan Capacitor Details
Tips: Are the “principles” of non-polarized and polarized capacitors the same?
The answer is the same, both non-polarized and polarized capacitors store and release charge, and the voltage on the pole plate (here the electric potential of charge accumulation is called voltage) cannot be changed suddenly.
The difference lies in the different medium, different performance, different capacity, different structure, and different environment and usage. In turn, according to the needs of production practice, people have experimented and manufactured various functions of capacitors to meet the normal operation of various electrical appliances and new equipment. With the development of science and technology and the discovery of new materials, better quality and diversified capacitors will emerge.
