Description
Note: This electric butterfly valve cannot be used for drinking water.
Factory price 10 inch electric butterfly valve is equipped with an aluminum alloy electric actuator to work. Our electric actuated butterfly valve can work at high temperature below 120 °C, which is a reliable device for flow control.
Specification
| Butterfly Valve | Model | ATO-EBV-250WF |
| Media | Water, Air, Gas, Oil, Liquid, etc. | |
| Butterfly Valve Type | Wafer Type | |
| Port Size | 10 inch (DN250, 250mm) | |
| Body Material | Cast Iron | |
| Disc Material | Stainless Steel (SS) | |
| Seat Material | EPDM | |
| Working Temperature | -10 °C to 120 °C | |
| Electric Actuator | Model | ATO-KLST-60 |
| Frequency | 50/ 60Hz | |
| Power Supply (Optional) | 110V AC, 220V AC, 380V AC, 24V DC | |
| Actuator Input | 4-20mA DC | |
| Actuator Type | Double Acting | |
| Output Torque & Response Time | 150N.m, 9s 250N.m, 15s 400N.m, 20s 600N.m, 30s/ 60s |
|
| Actuator Material | Aluminum Alloy |
Wafer Butterfly Valve Body Dimension (Unit: mm)
| DN | L | H1 | H2 | A | D | D1 | N-φd |
| 250 | 65.5 | 203 | 532 | 255 | 357 | 319 | 4-29 |
Details
Tips: How to maintain an electric actuated butterfly valve?
- Each spring of the electric butterfly valve is only suitable for a certain range of outlet pressure, and the spring beyond this range should be replaced.
- When the working temperature of the medium is high, the pilot piston type electric butterfly valve or the pilot metal bellows type electric butterfly valve is generally used.
- When the medium is gas or water, the quick-acting diaphragm type electric butterfly valve or the pilot diaphragm type electric butterfly valve is generally selected.
- When the medium is steam, pilot piston type or pilot metal bellows type electric butterfly valve should be used.
- In order to facilitate the actual operation, adjustment and maintenance, the electric butterfly valve should generally be installed on the horizontal pipe.
