Description
Mini 2000 Watt wind turbine generator for sale. With a safe wind resistance up to 45m/s, horizontal axis wind generator ensures steady energy generation. Automatic windward adjustment, electromagnetic braking. Compact windmill design, high efficiency, low vibration, strong wind resistance.
Specification
| Model | ATO-NE-2000L1 |
| Rated Power | 2000W |
| Maximum Power | 2300W |
| Rated Voltage | 48V/96V (optional) |
| Starting Wind Speed | 2.5m/s |
| Rated Wind Speed | 10m/s |
| Safe Wind Speed | ≤45m/s |
| Blade Length | 1.68m |
| Number of Blades | 3 |
| Blade Material | Reinforced Fibreglass |
| Generator Type | Rare Earth Permanent Magnet Generator |
| Magnetic Steel Material | NdFeB |
| Braking Method | Electromagnetism |
| Wind Adjustment | Automatic windward adjustment |
| Working Temperature | -40~80°C |
Features
- Compact Portable Design: Small wind generator suitable for home and marine applications.
- Wide Application Range: 2000W horizontal axis wind turbine works for caravan, offshore and onshore power supply.
- Efficient Wind Utilization: High energy conversion with low start-up speed and minimal vibration.
- Durable Construction: Strong wind resistance capability ensures reliable operation in various conditions.
- Flexible Voltage Options: 48V or 96V operation allows the portable wind generator to integrate seamlessly with various power systems.
- User-Friendly Installation: Simple setup process with automatic windward adjustment feature.
Structure Diagram
| 1. Fairing | 8. Bolt | 15. Flat washer |
| 2. Wind turbine hub | 9. Flat washer | 16. Elastic washer |
| 3. Wind turbine front body | 10. Nut | 17. Nut |
| 4. Wind turbine rear body | 11. Tail rudder plate | 18. Anti-loosening nut |
| 5. Anti-loosening nut | 12. Wind turbine flange seat | 19. Stainless steel screw |
| 6. Tail rudder fixing tube | 13. Rubber washer | 20. Wind blade |
| 7. Tail rudder | 14. Bolt | 21. Steel pipe bracket (tower) |
Application
Tips: Can the 2000W horizontal axis wind turbine be used in industry?
Yes, Mini 2000 Watt horizontal axis wind generator is perfectly suited for industrial applications where reliable auxiliary power is needed. Robust 48V/96V output efficiently supports essential systems like monitoring equipment, telecommunications, and lighting, making windmill generator an ideal renewable energy solution for remote industrial sites and automated facilities.
