Description
Good price adjustable speed electric motor with 2-pole/ 4-pole/ 6-pole for selection, rated current 11.2A/ 12A/ 13.4A, F grade insulation, IP55 protection grade. This type of induction motor is widely used in places that require energy-saving continuous operation and frequent work, such as air compressors, injection molding machines, water pumps.
Specification
| Model | ATO-VSM-132S1 | ATO-VSM-132S | ATO-VSM-132M2 |
| Numbers of pole | 2P | 4P | 6P |
| Rated current | 11.2A | 12A | 13.4A |
| Rated torque | 17.5Nm | 35Nm | 52.5Nm |
| Locked-rotor torque/ rated torque | 2.2 Tst/ Tn | 2 Tst/ Tn | 1.9 Tst/ Tn |
| Minimum torque/ rated torque | 1.2 Tmin/ Tn | 1.4 Tmin/ Tn | 1.3 Tmin/ Tn |
| Weight | 87kg | 81kg | 87kg |
| Constant power frequency conversion range | 50-60Hz | 50-100Hz | |
| Rated power | 7.5hp (5.5kW) | ||
| Mounting types | B3 | ||
| Rated voltage | 380V (380V-480V can be customized) | ||
| Fan voltage | 380V | ||
| Constant torque frequency conversion range | 3-50Hz | ||
| Locked-rotor current/ rated current | 9 Ist/ In | ||
| Maximum torque/ rated torque | 2.8 Tmax/ Tn | ||
| Certificate | CE | ||
| Warranty | 12 months |
Dimension
| Frame size | Mounting dimensions (mm) | Overall dimensions (mm) | ||||||||||||
| A | B | C | D | E | F | G | H | K | AB | AC | AD | HD | L | |
| 132S | 216 | 140 | 89 | 89 | 80 | 10 | 33 | 132 | 12 | 280 | 275 | 210 | 315 | 535 |
| 132M | 216 | 178 | 89 | 89 | 80 | 10 | 33 | 132 | 12 | 280 | 275 | 210 | 315 | 575 |
Details
Tips: Working Principle of Variable Speed Motor.
Inverter is an electric energy control device that uses the on-off action of power semiconductor devices to transform a power frequency power supply into another frequency. At the beginning of the 21st century, the frequency converter used mainly adopts AC-DC-AC (VVVF frequency conversion or vector control frequency conversion). First, the industrial frequency AC power supply is converted into DC power supply through the rectifier, and then the DC power supply is converted into frequency and voltage. Control AC power to supply the motor. The circuit of the frequency converter is generally composed of four parts: rectification, intermediate DC link, inverter and control. The rectification part is a three-phase bridge uncontrollable rectifier, the inverter part is an IGBT three-phase bridge inverter, and the output is a PWM waveform, and the intermediate DC link is filtering, DC energy storage and buffering reactive power.
