Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Open
- Body Material: Aluminum
- Flow (Cv): 4.6 Cv
- Pipe/Port Type and Size: NPT 3/4
- Media: Air, Inert Gas, Fuel Gas
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 77°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 104°
- Product Weight: 0 lbs
- Voltage and Frequency: 220 AC with 50 Hz
- Watt Rating: 10.5 W
- Holding Current (VA): 23
- Orifice Size: 3/4 in
- Coil Class: F
- Coil Number: 064982-005-D
- Lead Length: Vertical and Upright, 18 inch
- Carton Note: 3/4 X 3/4 2NO AL 10.5/F AC
- Kit Number: 302361
