Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 32 Cv
- Pipe/Port Type and Size: NPT 1-1/4
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 104°
- Product Weight: 0 lbs
- Voltage and Frequency: 110 AC with 50 Hz
- Watt Rating: 15.4 W
- Holding Current (VA): 24
- Orifice Size: 1-5/8 in
- Coil Class: FT
- Coil Number: 099257-001-D
- Mounting Direction: Vertical and Upright, 18 inch
- Carton Note: 1-1/4 X 1-5/8 2NC AL 15.4/F AC
- Kit Number: 302352-VH
