Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 5.1 Cv
- Pipe/Port Type and Size: NPT 3/4
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 125°
- Product Weight: 1.81 lbs
- Voltage and Frequency: 110, 120 Volts AC with 50/60 Hz
- Watt Rating: 10.1 W
- Holding Current (VA): 25
- Orifice Size: 3/4 in
- Coil Class: FT
- Coil Number: 238610-032-D
- Mounting Direction: 18 inch, Any
- Carton Note: 3/4 X 3/4 2NC AL 10.1/F AC
- Kit Number: 304089
