Description
Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Closed
- Body Material: Brass
- Flow (Cv): 3.2 Cv
- Pipe/Port Type and Size: NPT 1/2
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 104°
- Max Fluid Temperature: 120°
- Product Weight: 4.1 lbs
- Watt Rating: 22.6 W
- Orifice Size: 5/8 in
- Coil Class: FB
- Coil Number: 238710-106-D
- Mounting Direction: ANY, 18 inch
- Carton Note: 1/2 X 5/8 3NC BRASS 22.6/F DC
- Kit Number: 314497-V
