Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 4 way
- Body Material: Brass
- Flow (Cv): 0.8 Cv
- Pipe/Port Type and Size: NPT 3/8
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 125°
- Min Fluid Temperature: 32°
- Max Fluid Temperature: 180°
- Product Weight: 4.63 lbs
- Voltage and Frequency: 115 AC with 50 Hz
- Watt Rating: 17.1 W
- Holding Current (VA): 40
- Orifice Size: 1/4 in
- Coil Class: FB
- Coil Number: 238610-133-D
- Mounting Direction: Any, 18 inch
- Carton Note: 3/8 X 1/4 4W BRASS 17.1/F AC
- Kit Number: 302710
