Description
Specifications
- Valve Actuation: Solenoid
- Function: 2 way – 2/2 Normally Closed
- Body Material: Aluminum
- Flow (Cv): 53 Cv
- Pipe/Port Type and Size: NPT 1 1/2
- Media: Air, Inert Gas
- Min Operating Pressure (Air): 5 psi
- Max Operating Pressure (Air): 125 psi
- Voltage and Frequency: 110, 120 Volts AC with 50/60 Hz
- Watt Rating: 10.1 W
- Holding Current (VA): 25
- Orifice Size: 2 in
- Coil Class: FT
- Coil Number: 238610-032-D
- Mounting Direction: Any, 18 inch
- Carton Note: 1-1/2 X 2 2NC ALUM 10.1/F AC
- Kit Number: 322108
- Order Code: 21542
