Description
Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Closed
- Body Material: Brass
- Flow (Cv): 12.5 Cv
- Pipe/Port Type and Size: NPT 1
- Media: Air, Inert Gas, Water
- Min Operating Pressure (Air): 10 psi
- Max Operating Pressure (Air): 150 psi
- Min Operating Pressure (Water): 10 psi
- Max Operating Pressure (Water): 125 psi
- Product Weight: 7.81 lbs
- Voltage and Frequency: 240 AC with 60 Hz
- Watt Rating: 6.1 W
- Orifice Size: 1 in
- Coil Class: F
- Coil Number: 238214-058-D
- Mounting Direction: 18 inch, ANY
- Carton Note: 1 X 1 3NC BRASS 6.1/F AC
- Kit Number: 302661-MO
