Description
Specifications
- Valve Actuation: Solenoid
- Function: 4 way
- Body Material: Aluminum
- Flow (Cv): 0.86 Cv
- Pipe/Port Type and Size: NPT 1/4
- Media: Air, Inert Gas
- Min Operating Pressure (Air): 30 psi
- Max Operating Pressure (Air): 150 psi
- Min Ambient Temperature: 5°
- Max Ambient Temperature: 104°
- Min Fluid Temperature: 5°
- Max Fluid Temperature: 104°
- Voltage and Frequency: 110, 120 Volts AC with 50/60 Hz
- Watt Rating: 6.3 W
- Holding Current (VA): 7
- Orifice Size: 1/4 in
- Coil Class: FT
- Coil Number: 266762-902-D
- Lead Length: 18 inch
- Carton Note: 1/4 X 1/4 4W ALUM 6.3/F AC
- Order Code: 21599
