Description
Specifications
- Valve Actuation: Solenoid
- Function: 3 way – 3/2 Normally Closed
- Body Material: Brass
- Flow (Cv): 4.8 Cv
- Pipe/Port Type and Size: NPT 3/4
- Media: Air, Inert Gas, Water
- Min Operating Pressure (Air): 10 psi
- Max Operating Pressure (Air): 250 psi
- Min Operating Pressure (Water): 10 psi
- Max Operating Pressure (Water): 250 psi
- Product Weight: 4.5 lbs
- Voltage and Frequency: 120 AC with 60 Hz
- Watt Rating: 17.1 W
- Orifice Size: 11/16 in
- Coil Class: H
- Coil Number: 238814-132-D
- Mounting Direction: 18 inch, ANY
- Carton Note: 3/4 X 11/16 3NC BRASS 17.1/H AC
- Kit Number: 314495-MO
