ASCO HT8316G064MBDC24/DCD – Solenoid Valve

Description

Specifications

• Valve Actuation: Solenoid
• Function: 3 way – 3/2 Normally Closed
• Body Material: Brass
• Flow (Cv): 3.2 Cv
• Pipe/Port Type and Size: NPT 1/2
• Media: Air, Inert Gas, Water
• Min Operating Pressure (Air): 10 psi
• Max Operating Pressure (Air): 125 psi
• Min Operating Pressure (Water): 10 psi
• Max Operating Pressure (Water): 125 psi
• Product Weight: 3.9 lbs
• Watt Rating: 10.6 W
• Orifice Size: 5/8 in
• Coil Class: H
• Coil Number: 238510-006-D
• Lead Length: ANY, 18 inch
• Carton Note: 1/2 X 5/8 3NC BRASS 10.6/H DC
• Kit Number: 314493
