Description
Specifications
- Valve Actuation: Solenoid – Direct Acting
- Function: 2 way – 2/2 Normally Open
- Body Material: Aluminum
- Flow (Cv): 4.6 Cv
- Pipe/Port Type and Size: NPT 3/4
- Min Ambient Temperature: 32°
- Max Ambient Temperature: 104°
- Product Weight: 2.49 lbs
- Voltage and Frequency: 24 Volts AC with 60 Hz
- Watt Rating: 10.1 W
- Orifice Size: 3/4 in
- Coil Class: F
- Coil Number: 238612-005
- Mounting Direction: Any
- Carton Note: 3/4 X 3/4 2NO AL 10.1/F AC
- Kit Number: 302361
