Description
The industrial canister load cell is built for scales, with a strong 42CrMo steel structure that resists fatigue and maintains accuracy under repeated loads. Its alloy steel construction resists moisture and dust, while the aviation connector ensures stable and reliable signal transmission.
Note: The load cell cannot be connected to both the transmitter and the controller at the same time — only one can be selected.
Specification
| Model | ATO-DYZ-011 |
| Matched Transmitter | ATO-LCTR-OA (Click it to the transmitter page) |
| Matched Display Controller | ATO-DPM-DY800 (Click it to the controller page) |
| Output Sensitivity | 2.0/3.0 ±10% mV/V |
| Zero Balance | ±2% F.S. |
| Non-linearity | 0.3% F.S. |
| Hysteresis | 0.1% F.S. |
| Repeatability | 0.1% F.S. |
| Creep (30 minutes) | 0.05% F.S. |
| Temperature Effect on Sensitivity | 0.05% F.S./10°C |
| Temperature Effect on Zero | 0.05% F.S./10°C |
| Response Frequency | 1 kHz |
| Material | Alloy Steel |
| Input/Output Resistance | 700 Ω |
| Insulation Resistance | ≥5000 MΩ / 100 V DC |
| Excitation Voltage | DC 5–10 V |
| Operating Temperature Range | -20–80°C |
| Safe Overload | 150% R.C. |
| Ultimate Overload | 200% R.C. |
| Weight | 0.9kg, 1.34kg, 4kg, 4kg, 9kg, 16kg, 30kg, 57kg, 125kg |
Detail
- 42CrMo Alloy Steel: Canister load cells made of 42CrMo alloy steel offer strong fatigue resistance and excellent hardenability, providing high toughness under repeated loads and ensuring reliable performance after heat treatment.
- 5.6 mm Outer Diameter Wire: The 5.6 mm outer diameter wire delivers stable signal transmission and strong interference resistance, ensuring reliable performance even in challenging environments.
- Aviation Connector: Equipped with an aviation connector, the canister load sensor ensures secure and reliable electrical connections, delivering stable signal transmission and excellent resistance to vibration, moisture, and harsh industrial environments.
Size (unit: mm)
| Capacity (ton) | 300 | 500-650 | 700-1000 |
| ΦA | 154 | 196 | 246 |
| ΦB | 154 | 196 | 246 |
| C | 170 | 220 | 282 |
| D | M8 | M10 | M16 |
| E | 120 | 150 | 190 |
| R | 300 | 400 | 500 |
| G | 225 | 285 | 364 |
| F | 85 | 110 | 132 |
Wiring
Tips: Why choose a canister load cell for high capacity?
The canister load cell features a symmetrical cylindrical structure that distributes compression forces evenly across the sensing element. This design minimizes stress concentration and enhances structural strength, making it highly suitable for heavy-load measurement. Its solid construction provides excellent resistance to deformation under extreme loads, while maintaining stable and accurate output. For high-capacity systems such as truck scales, silos, and industrial platforms, the canister design ensures long-term durability, safety, and reliable performance even under continuous heavy-duty operation.
